| Größen |
6,5-Zoll, 7,7-Zoll oder 8,8-Zoll |
| Modell/Farbe |
Weißer oder grauer Sportgrill |
| Größe (Durchmesser x Tiefe) |
6,5-Zoll-Lautsprecher: 176 x 103,1 mm (6,93-Zoll x 4,06-Zoll) 7,7-Zoll-Lautsprecher: 196 x 113,2 mm (7,72-Zoll x 4,46-Zoll) (196 x 113,2 mm) 8,8-Zoll-Lautsprecher: 224 x 134,1 mm (8,82-Zoll x 5,28-Zoll) |
| Wasser- und Staubbeständigkeit |
IP66/IP67 |
| Konfiguration |
Koaxial |
| Spitzenleistung |
6,5-Zoll-Lautsprecher: 300 W 7,7-Zoll-Lautsprecher: 400 W 8,8-Zoll-Lautsprecher: 520 W |
| Effektive Leistung |
6,5-Zoll-Lautsprecher: 75 W 7,7-Zoll-Lautsprecher: 100 W 8,8-Zoll-Lautsprecher: 130 W |
| Empfindlichkeit (1 Watt bei 1 Meter) |
6,5-Zoll-Lautsprecher: 90 dB 7,7-Zoll-Lautsprecher: 91 dB 8,8-Zoll-Lautsprecher: 91 dB |
| Frequenzgang |
6,5-Zoll-Lautsprecher: 70 Hz bis 22 kHz 7,7-Zoll-Lautsprecher: 60 Hz bis 22 kHz 8,8-Zoll-Lautsprecher: 50 Hz bis 20 kHz |
| Nominale Impedanz |
4 Ohm |
| Empfohlene Verstärkerleistung (eff.) |
6,5-Zoll-Lautsprecher: 25 bis 150 W/Kanal 7,7-Zoll-Lautsprecher: 30 bis 200 W/Kanal 8,8-Zoll-Lautsprecher: 40 bis 260 W/Kanal |
| LED-Beleuchtung |
Ja (CRGBW; 5 Farben) |
| LED-Versorgungsspannung |
10,8 bis 16 V Gleichspannung |
| LED-Laststrom bei 14,4 V Gleichspannung |
6,5-Zoll-Lautsprecher: 0,13 A pro Farbe und Lautsprecher 7,7-Zoll-Lautsprecher: 0,14 A pro Farbe und Lautsprecher 8,8-Zoll-Lautsprecher: 0,18 A pro Farbe und Lautsprecher |
| LED-Laststrom bei 14,4 V Gleichspannung bei Verwendung von Garmin Spectra™1 |
6,5-Zoll-Lautsprecher: Maximal 0,28 A pro Lautsprecher 7,7-Zoll-Lautsprecher: Maximal 0,31 A pro Lautsprecher 8,8-Zoll-Lautsprecher: Maximal 0,38 A pro Lautsprecher |
| BETRIEBSTEMPERATUR |
0 °C bis 50 °C |
| Durchmesser der Schwingspule |
6,5-Zoll-Lautsprecher: 1,2-Zoll 7,7-Zoll-Lautsprecher: 1,4-Zoll 8,8-Zoll-Lautsprecher: 1,5-Zoll |
| Konusmaterial |
CURV® Konus Technologie mit Sicke aus Gummi |
| Art des Hochtöners |
6,5-Zoll-Lautsprecher: 1-Zoll-Seidenkalotte 7,7-Zoll-Lautsprecher: 1-Zoll-Seidenkalotte 8,8-Zoll-Lautsprecher: 1,25-Zoll-Seidenkalotte |
| Sicherheitsabstand zum Kompass |
6,5-Zoll-Lautsprecher: 280 cm (9,19 Fuß) 7,7-Zoll-Lautsprecher: 300 cm (9,84 Fuß) 8,8-Zoll-Lautsprecher: 315 cm (10,33 Fuß) |
| Lautsprecherverbindung |
Wasserbeständiger 2-Wege-Anschluss (2 Pins, positiv und negativ für Audio), 150 mm (5,9-Zoll) oder Kabelschuhe (Stecker; 6,3 mm (0,25-Zoll) positiv und 4,8 mm (0,19-Zoll) negativ) |
| LED-Verbindung |
Wasserbeständiger 6-Wege-Anschluss (6 Pins, für CRGBW und Masse), 150 mm (5,9-Zoll) |
| GARANTIE |
3 Jahre |
