| Tuner | AM/FM with RDS where available |
|---|
| Tuner Region | USA – Australasia – Europe – Japan |
|---|
| Multi-Language User Interface | English, French, German, Spanish, Dutch, Italian |
|---|
| Peak Power | 280W Max (@ 2 ?) |
|---|
| Amplifier | Class-D: 4 x 26 W rms @ 14.1Vdc input, 4O, = 10% THD+N. 4 x 43 W rms @ 14.4Vdc input, 2 O, = 10% THD+N |
|---|
| Audio Zones | 4 Zones (Zone 1 & 2 powered by internal amplifier) + 4 Line Out zones |
|---|
| Nameable Zones | Yes – Up to 10 characters per zone |
|---|
| Line Out | 4 (1 x L + R Per zone, all require amplification) |
|---|
| Sub Out | 4 (1 per zone, all require amplification) |
|---|
| Auxiliary Inputs | 2 x stereo RCA inputs (AUX1, AUX2) |
|---|
| iPod/iPhone | Made for iPod and iPhone |
|---|
| Album Art | Available via USB on supported Apple, MTP (Android/Windows) and USB flash drive devices |
|---|
| Display | 16:9 WQVGA color widescreen optically bonded LCD |
|---|
| NMEA 2000 | NMEA 2000 Certified LEN: 1 |
|---|
| Fusion-Link | Compatible with NRX Series wired remote and supported Multi-Function Displays (MFDs) for wired control via NMEA 2000 or Ethernet (visit www.fusion-link.com for compatible MFDs). Wireless control is available with the Fusion-Link remote control app, available for free download for compatible Apple and Android devices. |
|---|
| Bluetooth | A2DP audio streaming with AVRCP support (album art is not supported). |
|---|
| USB | 1 x USB connector |
|---|
| MTP (Media Transfer Protocol) | Support for compatible Windows & Android media devices via USB |
|---|
| Audio/Video/USB Format | MP3, M4A, FLAC, CDA, DVD |
|---|
| SiriusXM-Ready™ | (USA Only.) Requires SiriusXM Connect vehicle tuner (sold separately). For more information visit www.siriusxm.com. |
|---|
| DVD Playback | hdmi connector outputting standard definition 576i for DVD playback |
|---|
| CD Playback | CD/CD-R disks supported |
|---|
| Water Resistance | 360° IPx5 water resistant fully sealed chassis |
|---|
| Chassis | Electrically isolated Glass Filled Composite with Aluminum Heat Sink |
|---|
| DAB+ Ready | MS-DAB100A is required for DAB support, only available where DAB and DAB+ is broadcast |
|---|
| Compatible Apple Devices | iPhone X, iPhone 8, iPhone 8 Plus, iPhone 7, iPhone 7 Plus, iPhone SE, iPhone 6s, iPhone 6s Plus, iPhone 6, iPhone 6 Plus, iPhone 5s, iPhone 5c, iPhone 5, iPhone 4s, iPod Touch (5th and 6th gen) |
|---|
